Sweep
The probe scans the configured bands continuously, at fixed points or on vehicles.
Catalog / RF & wireless measurement / HW-RF02
HW-RF02Hardware · RF & wireless measurementFeatured
RF Spectrum Analyzer Probe
The RF Spectrum Analyzer Probe gives industrial sites continuous visibility of the radio spectrum. It sweeps from 240 MHz to 6.1 GHz in receive-only mode, so it can run next to critical radios without affecting them, and it reveals interference that link KPIs alone cannot explain.
Key capabilities
What it does.
- 01
Receive-only spectrum sweeps from 240 MHz to 6.1 GHz
- 02
Detects unauthorized emissions, co-channel interference and noise-floor rise
- 03
Fixed indoor, outdoor or vehicle installation
- 04
Feeds the RF Spectrum Usage Measurement System and MCM Center
How it works
Three steps from field to decision.
Step 1
Step 2
Compare
Measurements are compared with the authorized frequency plan of the site and with the historical noise floor.
Step 3
Alert
Unauthorized emissions, co-channel interference and noise-floor rise trigger alarms and appear on the site map.
Technical highlights
- Frequency range
- 240 MHz to 6.1 GHz
- Mode
- Passive, receive-only
- Interfaces
- Ethernet, USB, optional LTE backhaul
- Housing
- Indoor or IP67 outdoor
- Power
- PoE or 12/24 VDC
Indicative specifications. Final configuration, enclosure and certifications are confirmed per project.
Typical applications
- Interference hunting on private wireless networks
- Spectrum-use documentation per site
- Monitoring of licensed and unlicensed bands near critical links
Industries
MiningTelecom & private networksEnergy & utilitiesPorts & logistics
Sales model
100% B2B. ITTC products are supplied through specialized partner companies in each vertical. Contact us to find the partner for your sector, or to become one.
Contact sales
