Survey
Carry the probe on foot, mount it on a vehicle or leave it at a fixed point.
Catalog / RF & wireless measurement / HW-RF03
HW-RF03Hardware · RF & wireless measurementConfigured
Wi-Fi Survey Probe
The Wi-Fi Survey Probe records the real Wi-Fi environment along any route. It works in passive monitor mode, so it captures every access point and channel without joining a network, and each sample is stored with its position for heatmaps and channel planning.
Key capabilities
What it does.
- 01
Passive monitor-mode scan of 2.4, 5 and 6 GHz bands
- 02
Records SSID, BSSID, channel, band and RSSI with GPS position
- 03
Walk, drive or fixed survey modes
- 04
Exports to Wi-Fi Heatmap Studio, MCM Center or CSV
How it works
Three steps from field to decision.
Step 1
Step 2
Record
It logs SSID, BSSID, channel, band and signal strength with GPS or floor-plan position.
Step 3
Visualize
Wi-Fi Heatmap Studio or MCM Center turns the data into coverage, interference and capacity maps.
Technical highlights
- Standards
- 802.11 a/b/g/n/ac/ax
- Bands
- 2.4 / 5 / 6 GHz
- Positioning
- GNSS or manual floor plan
- Power
- USB-C battery pack or 12 VDC
- Mode
- Passive, no association required
Indicative specifications. Final configuration, enclosure and certifications are confirmed per project.
Typical applications
- Pre- and post-deployment Wi-Fi surveys
- Rogue access point detection
- Channel planning in congested plants
Industries
ManufacturingMiningPorts & logisticsTelecom & private networks
