Mount
Place the puck antenna on the vehicle roof with the magnetic or bolt mount.
Catalog / RF & wireless measurement / HW-RF05
HW-RF05Hardware · RF & wireless measurementStandard
GNSS Drive-Test Receiver
The GNSS Drive-Test Receiver adds accurate positioning to any measurement setup. It tracks several satellite constellations and outputs standard NMEA sentences, so radios, laptops and probes that lack a good GPS can produce georeferenced data for heatmaps and coverage reports.
Key capabilities
What it does.
- 01
High-sensitivity multi-constellation GNSS receiver
- 02
NMEA 0183 output over USB or serial
- 03
Stable positioning for georeferenced RF measurements
- 04
Magnetic or bolt mount for vehicles
How it works
Three steps from field to decision.
Step 1
Step 2
Connect
Plug it into the laptop, probe or radio over USB or serial.
Step 3
Measure
Every RF sample is tagged with position, speed and heading at up to 10 Hz.
Technical highlights
- Constellations
- GPS, GLONASS, Galileo, BeiDou
- Update rate
- 1 to 10 Hz
- Output
- NMEA 0183, USB or RS-232
- Housing
- IP67 puck antenna
- Power
- 5 VDC over USB
Indicative specifications. Final configuration, enclosure and certifications are confirmed per project.
Typical applications
- Drive tests and coverage campaigns
- Adding GPS to radios or laptops without one
- Reference position for RF measurement probes
Industries
MiningTelecom & private networksRail & transportPorts & logistics
Sales model
100% B2B. ITTC products are supplied through specialized partner companies in each vertical. Contact us to find the partner for your sector, or to become one.
